Commercial / Industrial V Bank Filter For HVAC System Dove Tailed Neoprene Gasket

Name: Commercial Industrial V Bank Filter For HVAC System Dove Tailed Neoprene Gasket
Brand: XNGK
Price: 1 USD

China Commercial / Industrial V Bank Filter For HVAC System Dove Tailed Neoprene Gasket wholesale

Brand Name : XNGK

Model Number : XN-VB1

Certification : CE ROHS

Place of Origin : China

MOQ : 1

Price : Negotiable

Payment Terms : Western Union, T/T

Delivery Time : 10 - 20 working days

Packaging Details : Plastic bag inside, carton box outside, wooden case if required

Frame : ABS Plastic

Filter media : Glass fiber or polyester

Filter Efficiency : Merv 15

Application : Industrial or Commercial HVAC system

Service life : 1 - 1.5 years

Separator : hot-melt

Gasket : EVA

Contact Now

V Bank Filter for Commercial and Industrial HVAC system F7 F8 F9 EN:779

Features for V bank filters

100% synthetic filter media, impervious in moist environment;
V shape design, maximize filter area in limited space;
Plastic frame, anti-corrosion in high moist, high acid or alkali situations;
Pleated filter media is sealed by polyurethane all around the perimeter;
Hot-melt separator antibacterial;
Low resistance, high air flow rate design;
Dove tailed gasket behind the flange ensure air tight;
Synthetic or glass fiber paper available;
Wide range efficiency from F7 to H10 available;

Applications

The V bank filter is an optional replacement for pocket filter, improve air filtration efficiency for medium stage, increase operating period of HEPA filters;

Flange size, 25mm thickness;

The V bank filters ABS frame is flammable and won`t produce poisonous gases;

Specification Data

Size	Efficiency	Air Flow	Resistance
595595292 mm	F8	3600 m³/h	125 Pa
595287292 mm	F8	1800 m³/h	135 Pa

Other size and specification available;

Resistance range: ±15%

Commercial / Industrial V Bank Filter For HVAC System Dove Tailed Neoprene Gasket

Product Tags:

merv 11 efficiency air filter

hvac carbon filter

Commercial / Industrial V Bank Filter For HVAC System Dove Tailed Neoprene Gasket Images
